EKA GT MAX
The next generation of Industrial LCD 3D Printers. Engineered for professional-grade precision with a massive 16-inch 8K screen and smart automation features.
Precision. Power. Perfection.
Advanced features for continuous industrial production.
16" 8K Resolution
Features a massive 7680×4320 resolution monochrome LCD, delivering crisp details and exceptional surface quality even on the largest parts.
46μm Ultra-Precision
With a pixel size of just 46 microns, the GT MAX surpasses most printers in its class, offering surreal detailing and dimensional accuracy.
Auto Resin Feeding
Smart auto-feed system ensures uninterrupted printing by automatically refilling the resin tank, reducing manual intervention for large builds.
Resin Tank Heating
Integrated temperature control maintains optimal resin viscosity, ensuring consistent success rates even in fluctuating environments.
Massive Volume
Industry-leading 353×198×400 mm build area allows for large-scale models or high-volume batch production in a single print run.
High Speed
Achieves print speeds up to 50 mm/hr without compromising detail, making it ideal for time-sensitive rapid prototyping.
Work From EKA GT MAX
See the capabilities of industrial 8K printing.
Technical Specifications
Built for precision and power, the EKA GT MAX is a robust industrial machine designed to operate 24/7 with minimal downtime.
- Technology: UV Surface Exposure LCD
- Screen: 16-inch 8K Monochrome (7680×4320)
- Pixel Size: 46 µm
- Light Source: 405 nm UV LED
- Z-Axis: Dual Linear Rails with Ball Screw
- Resin Management: Auto Feeding + Heating
- Calibration: Factory Pre-Calibrated
- Software: Chitubox Compatible
| Category | Specification |
|---|---|
| Build Volume | 353 × 198 × 400 mm |
| Printer Dimensions | 600 × 480 × 880 mm |
| Net Weight | 52 kg |
| Max Print Speed | Up to 50 mm/h |
| Layer Thickness | 0.01 – 0.3 mm |
| Operation | 7-inch Touchscreen |
| Connectivity | Wi-Fi, USB |
| Power Consumption | 300 W |
| Release Film | High-Speed TSP Film |
Ready to Scale Production?
Contact our experts to discuss your industrial printing needs and get a custom quote for the EKA GT MAX.
